PT-3001 pan tilt “25 kg load”
- Load capacity up to 25 kg
- RS-485 Pelco D serial control
- Made of Aluminum with stainless fittings
- Advanced positioning support
- AUX, extender and motorized lens control
Description
The PT-3001 pan tilt is a large size step motor pan tilt with a load capacity of up to 25 kg. Many advanced control features, absolute position, Pelco extended protocol, variable speed, presets, motorized lens and AUX control. The pan tilt is made of aluminum and all fittings are made of stainless steel.
The pan tilt is designed with step motors and worm gears, a combination to get a high load capacity and a strong hold capacity.
Many options are available and the pan tilt can be custom made to your specific application.
Specifications for PT-3001 step motor pan tilt head |
|
|---|---|
| Material | Aluminum |
| IP rating | IP66 |
| Load capacity | Top mount 25 kg (side mount brackets optional) |
| Size (LxHxW) | 281 x 423 x 244 mm |
| Weight | 19 kg |
| Pan angle | 0-345° |
| Tilt angle | -70° to +30° (-85 +85 optional) |
| Pan speed | 0,1 – 35°/sec (preset speed selectable 50,40,35,25,15,6°/sec) |
| Tilt speed | 0,1 – 10°/sec (preset speed selectable 20,10,9,8,7,6°/sec) |
| Absolute position support | Yes |
| Mechanical lash | <0,3° |
| Presets | 100 presets |
| Preset accuracy | <0,2° |
| Motor type | Step motor |
| Gear type | Worm gear |
| End-stop adjustable | Internally by mechanical end stops |
| Selftest | Automatic selftest at power ON |
| Interface | RS-485 |
| Baud rate | 2400, 4800, 9600, 19200 bps, N,8,1 |
| Protocol | Pelco D |
| Address | 1-256 |
| Temperature range | -10°C +60°C-(-25°C +60°C with optional heater) |
| Voltage supply | 230VAC to supply PSU junction box, output 32VAC, 230VAC |
| Power consumption | NA |
| Motorized lens control | Yes (4 wire lens control and presets voltages |
| Aux control | Yes (5 aux relays and 1 motorized extender control output) |
| Video cable | Yes (HDSDI cable optional) |
| Network cable | Optionally |
Options
-
360 degree endless rotation
Endless rotation option, for continuous 360 degrees rotation. High quality slip rings are installed to transmit power, video and control signals through the pan tilt unit.
-
Wiring and connectors
Custom wiring and connectors can be ordered, HDSDI or Network cable can be installed optionally.
-
Color
The pan tilt can be custom painted in many colors
-
Side mount
Side mount brackets are available and can be mounted on each side of the pan tilt.
-
Tripod
Heavy duty tripod made specifically for the PT-3001 pan tilt
-
Heater
Internal heater to extend the temperture range to -25°C
